AGE-U 050

ID 1312860

Compensatie-eenheid AGE-U, Maatuitvoering: 050, met vergrendeling

  • Compensatie XY: ± 2.7 mm
  • Compensatie Z: 6.1 mm
  • Gewicht werkstuk: 5 kg
  • Rotatie-afwijking: ± 8 °
  • Minimale terugloopkracht met ingebouwde veer: 36 N
  • Max. terugloopkracht met ingebouwde veer: 92 N
Do you have a question?
Download CAD file
Technical details
Compensatie XY* [mm] ± 2.7
Compensatie Z [mm] 6.1
Hoekuitwijking [°] ± 3
Rotatie-afwijking [°] ± 8
Aanbevolen handlingsgewicht, verticaal [kg] 5.0
Minimale terugloopkracht met ingebouwde veer [N] 36.0
Max. terugloopkracht met ingebouwde veer [N] 92.0
Min. werkdruk stijfheidaanpassing [bar] 0.3
Max. werkdruk stijfheidaanpassing [bar] 2.1
Min. bedrijfsdruk voor vergrendeling [bar] 4.1
Max. bedrijfsdruk voor vergrendeling [bar] 6.9
Aansluiting aan robotzijde ISO 9409-1-50-4-M6
Aansluiting aan gereedschapszijde ISO 9409-1-50-4-M6
Gewicht [kg] 0.6
Moment Mx max. [Nm] 6.8
Moment My max. [Nm] 6.8
Moment Mz max. [Nm] 3.4
*Tijdens de compensatie in de X-Y-richting trekt het product minimaal samen omwille van de conus op de overbelastingspin langs de Z-as. Raadpleeg de bedieningshandleiding voor meer informatie over het product.

Dimensions and maximum loads

Content available soon

Load chart

Content available soon

Compensation force Fd

Content available soon
Content available soon
Content available soon
Content available soon

Dimensions and maximum loads

This is the max. total of all moments and loads (acceleration forces and torques, process forces etc.), which can affect a compensation unit, in order to ensure error-free function.

Load chart

X-axis:
Momente Mx, My
Y-axis:
Angle in degrees
The indicated angular deflections are maximum values and depend on the operating pressure. In the locked state, the moment load caused by the mass of the customer-side tool and the acceleration must not lead to any deflection, otherwise the maximum number of load cycles is reduced, and the compensation unit can be damaged.

Compensation force Fd

X-axis:
Pressure
Y-axis:
Force
Compensating outside the operating pressure range for adjusting the stiffness reduces the maximum number of load cycles and may result in damage to the compensation unit.

General notes about the series

Harsh environmental conditions
Please note that use under harsh environmental conditions (e.g. in the coolant area, cast and grinding dust) can considerably reduce the service life of the units, and we will not take over any warranty. However, in many cases we can find a solution. Please contact us for assistance.

Handling weight
is the weight of the total load attached to the flange. When designing, the permissible forces and moments have to be paid attention to. Please note that exceeding the recommended handling weight will shorten the lifespan.

Actuation
Spring return with spring forces and compressed air

Housing
hard anodized aluminum alloy, functional parts made of hardened steel

Scope of delivery
Compensation unit in the ordered variant, elements for mechanical connection and safety information. Product-specific instructions can be downloaded at schunk.com/downloads-manuals.

Warranty
24 months

Drawings
Downloads
Accessories
