ROTA-S flex 1400

ROTA-S flex 1400

Weight-optimized 3-jaw manual chuck

ID 814850

Standard manual lathe chucks

Product features:
  • Weigth-optimized 3-Jaw Chuck, manually actuated
  • Jaw quick-change system
  • Used chuck: ROTA-S plus 630
  • Jaw interface: Angled serration
Technical data:
  • Stroke per jaw: 15 mm
  • Max. clamping force: 270 kN
  • Max. torque: 350 Nm
  • Max. RPM: 400 1/min
  • Max. rotary table torque: 8000 Nm
  • Weight: 830 kg
Do you have a question?
Download CAD file
Technical details
Serration Angled serration
Used chuck ROTA-S plus 630
Max. RPM [1/min] 400
Max. clamping force [kN] 270
Max. torque [Nm] 350
Stroke/jaw [mm] 15
Max. rotary table torque [Nm] 8000
Weight [kg] 830

Clamping force-RPM-diagram

Content available soon
Content available soon

Clamping force-RPM-diagram

X-axis:
n [min-1]
Y-axis:
Fsp [kN]
brown
SHF 630
red
SFA 630
green
Required minimum clamping force Fspmin 33%

Scope of delivery
Chuck, guideway extensions, long base jaws, short base jaws, centering pins, chuck cover, ratchet wrench, adapter for ratchet wrench, eye bolts, mounting screws, nuts for T-slot, bore cover plate, operating manual; without top jaws
