TM 16 Illustration similar

TM 16

Single T-nut

ID 148118

TM 16, Single T-nut

Product features:
  • Max. tightening torque: 250 Nm
  • Delivery unit: 1 piece
Tools:
  • Does this T-nut fit on my lathe chuck? In order to find the right T-nut for your lathe chuck, click "Tools" and use our chuck jaw quickfinder.
Do you have a question?
Download CAD file
Technical details
Produktgruppe Einzel-Nutenstein
Höhe H [mm] 25.0
Durchmesser D [mm] 24.5
Max. zul. Anziehdrehmoment [Nm] 250.0
Bei der Auswahl der Nutensteine bitte die Anschlussmaße des Futters (Verzahnung/Nutbreite) prüfen
