B 80-SRS-M-2010
- Max. stroke: 5220 mm
- Max. driving force: 4000 N
Technical details
| Máx. curso H [mm] | 5220.0 |
|---|---|
| Força máxima motriz [N] | 4000.0 |
| Precisão de repetição [mm] | ± 0.03 |
| Máx. comprimento total [mm] | 5600.0 |
| Máx. rapidez [m/s] | 0.5 |
| Máx. aceleração [m/s²] | 20.0 |
| Min. temperatura ambiente [°C] | 0.0 |
| Máx. temperatura ambiente [°C] | 80.0 |
| Peso morto da base incluindo corrediça [kg] | 5.4 |
| Massa adicional por curso de 100 mm [kg] | 0.7 |
| Peso da corrediça [kg] | 2.2 |
| Comprimento da placa deslizante [mm] | 210.0 |
| Sistema de guia | Guida a rulli |
| Diâmetro do rolo [mm] | 20.0 |
| Conceito de acionamento | Azionamento mandrino |
| Torque de marcha lenta [Nm] | 0.6 |
| Momento de inércia [kgm²] | 8.4E-5 |
| Diâmetro do eixo [mm] | 20.0 |
| Passo do fuso [mm] | 10 |
| Máx. velocidade do fuso [1/min] | 3000.0 |
| Comprimento X [mm] | 380.0 |
| Largura Y [mm] | 80.0 |
| Altura Z [mm] | 100.0 |
| Momento Mx máx. [Nm] | 50.0 |
| Momento My máx. [Nm] | 180.0 |
| Momento Mz máx. [Nm] | 100.0 |
| Força Fy máx. [N] | 500.0 |
| Força Fz máx. [N] | 1500.0 |
| Força -Fz máx. [N] | 800.0 |
Os suportes de fuso padrão SCHUNK com atenuação de ruído (SAG) reduzem o curso máximo em 10 mm para cada 2 SAG.
Observe que o momento de inércia dos eixos do fuso se refere a um metro.
Dimensions and maximum loads
Spindle supports**
Dimensions and maximum loads
The indicated forces and moments are maximum values for individual loading. If several forces and/or moments are applied at the same time, the maximum permitted individual values will be lower.
Spindle supports**
- X-axis:
- Axis length
- Y-axis:
- Speed of rotation
General notes about the series
Ambient conditions
The modules are mainly designed for the use in clean ambient conditions. Please note that the life time of the modules can shorten if they are used in harsh ambient conditions, and that SCHUNK cannot assume liability in such cases. Please contact us for assistance.
Max. stroke
is the maximum permissible stroke. Acceleration and braking distances or possible overrun must be taken into consideration.
Repeat accuracy
defined as the spread of the target position after 100 consecutive positioning cycles under constant conditions.
Acceleration and speed
The values specified are the maximum values of the units without loading. The actual accelerations and speeds for your application must be designed separately and can deviate from the maximum values.
Layout or control calculation
Verifying the sizing of the selected unit is necessary, since otherwise overloading can result. Please contact us for assistance.
Operating principle
Choice of toothed belt or ball screw spindle drive
Drive
servomotors of different providers can be trouble-free adapted
Profile
Extruded aluminum profile with plastic cover strip
Slide
Aluminum slide with a brush seal
Scope of delivery
Assembly and operating manual with declaration of incorporation
Warranty
24 months
